 ~!C

Description

This command inquires the presence of Real Time Clock. One byte is return from the printer, indicating

whether or not the RTC is installed. This command is only for the firmware before V6.xx.

Syntax

~!C

Parameter Description

None N/A

Return value Description

0 RTC is not installed.

1 RTC is installed.

Example

~!C

Other manuals for TSC TTP-244 Plus

Questions and Answers:

Need help?

Do you have a question about the TSC TTP-244 Plus and is the answer not in the manual?

General

Resolution	203 dpi
Print Speed	4 ips
Print Method	Thermal Transfer / Direct Thermal
Weight	2.5 kg
Max. Print Width	4.25 inches
Max. Print Length	90 inches
Processor	32-bit RISC CPU
Interface	RS-232
Label Width	1 inch to 4.4 inches
Power Supply	100-240V AC, 50/60Hz
Operating Temperature	5°C to 40°C
Storage Temperature	-40°C to 60°C
Humidity	25% to 85% non-condensing
Label Thickness	0.06 ~ 0.19 mm (2.36 ~ 7.48 mil)
Dimensions	232 mm (W) x 156 mm (H) x 288 mm (D)
