TSC TTP-244 Plus Programming Manual

TSC AUTO ID Technology Co., Ltd. 18 Copyright 2013 All Rights Reserved.
See Also
COUNTRY, ~!I
Sample Code
DOWNLOAD "TEST.BAS"
str1$ = ""
J = 0
y = 50
CODEPAGE 1252
SIZE 4,3
GAP 0,0
DIRECTION 1
CLS
TEXT 10,10,"COUR.TTF",0,12,12,"CODEPAGE 1252"
FOR I=32 TO 255
str1$=str1$+CHR$(I) + " "
J=J+1
IF J=16 THEN GOSUB drawTEXT
NEXT
PRINT 1
END
drawTEXT:
TEXT 10,y,"COUR.TTF",0,12,12,str1$
str1$=""
J=0
y=y+40
RETURN
EOP
TEST
Result

TSC TTP-244 Plus Specifications

General

Resolution	203 dpi
Print Speed	4 ips
Print Method	Thermal Transfer / Direct Thermal
Weight	2.5 kg
Max. Print Width	4.25 inches
Max. Print Length	90 inches
Processor	32-bit RISC CPU
Interface	RS-232
Label Width	1 inch to 4.4 inches
Power Supply	100-240V AC, 50/60Hz
Operating Temperature	5°C to 40°C
Storage Temperature	-40°C to 60°C
Humidity	25% to 85% non-condensing
Label Thickness	0.06 ~ 0.19 mm (2.36 ~ 7.48 mil)
Dimensions	232 mm (W) x 156 mm (H) x 288 mm (D)
