TSC TTP-244 Plus Programming Manual

TSC AUTO ID Technology Co., Ltd. 38 Copyright 2013 All Rights Reserved.
Code Type
Character sets
Max. data
length
128
See Character set for CODE128.
-
128M
See Character set for CODE128.
-
EAN128
0123456789
-
25
0123456789
Length is even.
25C
0123456789
Length is odd.
39 (C)
0123456789[Space]ABCDEFGHIJKLMNOPQRSTUVWXYZ
-.$/+%
-
39 (C) Full ASCII
0123456789[Space]ABCDEFGHIJKLMNOPQRSTUVWXYZ
!#$%&'()*+,-./:;<=>?@[\]^_`abcdefghijklmnopqrstuvwx
yz{|}~
-
93
0123456789[Space]ABCDEFGHIJKLMNOPQRSTUVWXYZ
!#$%&'()*+,-./:;<=>?@[\]^_`abcdefghijklmnopqrstuvwx
yz{|}~
-
EAN13
0123456789
12
EAN13+2
0123456789
14
EAN13+5
0123456789
17
EAN8
0123456789
7
EAN8+2
0123456789
9
EAN8+5
0123456789
12
CODA
0123456789-$:/.+
-
POST
0123456789
5, 9, 11
UPCA
0123456789
11
UPCA+2
0123456789
13
UPA+5
0123456789
16
UPCE
0123456789
6
UPCE+2
0123456789
8
UPE+5
0123456789
11
MSI
0123456789
-
MSIC
0123456789
-
PLESSEY
0123456789
-
CPOST
0123456789
-
ITF14
0123456789
13
EAN14
0123456789
13
11
0123456789-
-
TELEPEN
ASCII 0 to 127
30
TELEPENN
0123456789
60
PLANET
0123456789
38
CODE49
ASCII 0 to 127
81
DPI
0123456789
11
DPL
0123456789
13
LOGMARS
0123456789[Space]ABCDEFGHIJKLMNOPQRSTUVWXYZ
-.$/+%
-
Note:
Since V5.10EZ, \[R] means carriage return character 0x0D and \[L] means line feed character
0x0A.

TSC TTP-244 Plus Specifications

General

Resolution	203 dpi
Print Speed	4 ips
Print Method	Thermal Transfer / Direct Thermal
Weight	2.5 kg
Max. Print Width	4.25 inches
Max. Print Length	90 inches
Processor	32-bit RISC CPU
Interface	RS-232
Label Width	1 inch to 4.4 inches
Power Supply	100-240V AC, 50/60Hz
Operating Temperature	5°C to 40°C
Storage Temperature	-40°C to 60°C
Humidity	25% to 85% non-condensing
Label Thickness	0.06 ~ 0.19 mm (2.36 ~ 7.48 mil)
Dimensions	232 mm (W) x 156 mm (H) x 288 mm (D)
