TSC TTP-244 Plus Programming Manual

TSC AUTO ID Technology Co., Ltd. 64 Copyright 2013 All Rights Reserved.
number of bytes of binary data to be encoded.
*If "K" is the first character in the data string, then the following data
after "K" is Kanji data.
*If "!" is in the data string and follows by "N", "A", "B", "K" then it will be
switched to specified encodable character set.
Manual mode example:
QRCODE 100,10,L,7,M,0,M1,S1,"ATHE FIRMWARE HAS BEEN UPDATED"
(Where A: Alphanumeric data)
QRCODE 100,10,M,7,M,0,M1,S2,"N123456"
(Where N: Numeric data)
QRCODE 100,10,Q,7,M,0,M1,S3,"N123456!ATHE FIRMWARE HAS BEEN
UPDATED"
(Where N: Numeric data ; !:Transfer char ; A: Alphanumeric data)
QRCODE 100,10,H,7,M,0,M1,S3,"B0012Product name"
(where B: Binary data ; 0012: 12 bytes )
QRCODE 100,10,M,7,M,0,M1,S3,"K"
(Where K: Kanji data)
Auto mode example:
QRCODE 100,10,M,7,A,0,"THE FIRMWARE HAS BEEN UPDATED"
Model
QR Code
TTP-243 series
TTP-243 Plus series
V
TTP-244ME series
TTP-244ME Plus series
V
TTP-244 series
V
TTP-244CE series
V
TTP-245 series
V
TTP-245C series
V
TDP-245 series
V
TTP-246M series
V
TTP-248M series
TTP-2410M series
V
TDP-643 Plus
TDP-643R Plus
V
TTP-342 series
TTP-342 Plus series
V
TTP-342M series
TTP-342M Plus series
V
TTP-343 series
V
TTP-343C series
V
TTP-344M series
V
TTP-346M series
V
TTP-384M series
V
TTP-644M series
V
M23 series
V

TSC TTP-244 Plus Specifications

General

Resolution	203 dpi
Print Speed	4 ips
Print Method	Thermal Transfer / Direct Thermal
Weight	2.5 kg
Max. Print Width	4.25 inches
Max. Print Length	90 inches
Processor	32-bit RISC CPU
Interface	RS-232
Label Width	1 inch to 4.4 inches
Power Supply	100-240V AC, 50/60Hz
Operating Temperature	5°C to 40°C
Storage Temperature	-40°C to 60°C
Humidity	25% to 85% non-condensing
Label Thickness	0.06 ~ 0.19 mm (2.36 ~ 7.48 mil)
Dimensions	232 mm (W) x 156 mm (H) x 288 mm (D)
