TSC TTP-244 Plus Programming Manual

TSC AUTO ID Technology Co., Ltd. 86 Copyright 2013 All Rights Reserved.
Example
Test <ESC>!S by CommTool via RS-232 port.
Result
Item
Meaning
1
The start character of returned value.
2
The 4-byte status in Hex.
3
The end characters of returned value.
4
4-byte status in characters.
@@@@: The printer is normal for use.
F@@@: The printer is feeding label.
`@@@: Printer is in PAUSE mode.
B@@@: The printer is backing label.
E@@B: Printer is in error “Paper Jam”.
E@@b: Printer is in error “Paper Jam” & “Head
open”.
See Also
<ESC>!?
Hex Data 1B 21 53
means <ESC>!S.
The values return
from printer in Hex.
The values return
from printer in
Character.
Click to send Hex
1b 21 53 to query
printer status.
1
2
3
4

TSC TTP-244 Plus Specifications

General

Resolution	203 dpi
Print Speed	4 ips
Print Method	Thermal Transfer / Direct Thermal
Weight	2.5 kg
Max. Print Width	4.25 inches
Max. Print Length	90 inches
Processor	32-bit RISC CPU
Interface	RS-232
Label Width	1 inch to 4.4 inches
Power Supply	100-240V AC, 50/60Hz
Operating Temperature	5°C to 40°C
Storage Temperature	-40°C to 60°C
Humidity	25% to 85% non-condensing
Label Thickness	0.06 ~ 0.19 mm (2.36 ~ 7.48 mil)
Dimensions	232 mm (W) x 156 mm (H) x 288 mm (D)
