12 Interface
103
Interface
Chapter
12
■Data address
Type of data Address Data name
Setting value
LOCK
Calibration
LOCK
Data
format
Coil
0XXXX
00001 Hold ON
B1
00002 Hold OFF
00003 Digital zero
00004 Digital zero reset
00005 Hold reset
00006 Survival verification request ON
00007 Survival verification request OFF
00008 I/O output check
00009 BCD output check
00010 Zero calibration
○
00011 Actual load calibration
○
00012 Equivalent input calibration
○
Input status
1XXXX
10001 Hold
B1
10002 Stable
10003 Near zero output
10004 Overload (LOAD, OFL, warning)
10005 Zero tracking
10006 HI output
10007 LO output
10008 OK output
10009 HH output
10010 LL output
10011
Backup (not allocated)10012
10013
10014 Set value LOCK
B110015 Calibration LOCK
10016 Survival verification response
Input register
3XXXX
30001 Decimal place 0, 1, 2, 3
30002 0 fixed (reserved for units) 0 fixed
30003 Linked indicated value *1 I16
30004 Backup (not allocated)
30005 Non-linked indicated value *1, 3 I16
30006
Backup (not allocated)
～
30010
30011 Status 1
I1630012 Status 2
30013 Status 3
30014
Backup (not allocated)30015
30016
30017 Linked indicated value (HI)
I32
30018 Linked indicated value (LO)
30019 Non-linked indicated value (HI) *3
30020 Non-linked indicated value (LO) *3
