3-3. Setting procedure
Selection of
is displayed
Select the setting item
Setting begins when the most significant digit flashes
Select the digit to set
Change the setting value
The setting value is fixed
Setting mode ends and the screen returns to the indicated value display
"F1" of setting mode 1
Selection of
Setting selection,
"F2" of setting mode 2
is displayed.
Press the key to affix a sign to HI limit, LO limit, digital
offset, HH limit, LL limit, D/A zero setting, D/A full scale setting,
alarm HI limit, and alarm LO limit.
In case no key is operated for one minute after pressing the key and before
confirming the value with the key, setting will be interrupted and the indicator
will return to the indicated value display. In this case, a setting value is not recorded.
