140
15 Specifications
140
Specifications
Chapter
15
RS-232C communication interface
Signal level Based on RS-232C
Transmitting distance Roughly 15m
Transmitting method Asynchronous, full duplex
Transmitting speed Selectable from 1200, 2400, 4800, 9600, 19200, 38400 bps
Bit configuration Start bit 1bit
Character length Selectable from 7 or 8 bit
Stop bit Selectable from 1 or 2 bit
Parity bit Selectable from none, odd or even
Terminator Selectable from CR, CR-LF
Code ASCII
■General performance
Power supply voltage AC spec.: AC100 to 240V (+10%, -15%)
[Free power supply 50/60Hz]
DC spec.: DC12 to 24V (±15%)
(DC power supply is selectable at the time of order.)
Power consumption AC spec.: 10W max
DC spec.: 10W max
Rush current AC spec.: 2A, 1msec: with AC100V average load
(reference value) (ordinary temperature, at cold-start time)
4A, 1msec: with AC200V average load
(ordinary temperature, at cold-start time)
DC spec.: 2A, 20msec: with DC12V average load
(ordinary temperature, at cold-start time)
1A, 50msec: with DC24V average load
(ordinary temperature, at cold-start time)
Operating conditions Temperature: Operating temperature -10 to 40℃
Storage temperature -40 to +80℃
Humidity: 85% RH or less (no condensation)
Dimensions 96 (W) ×48 (H) × 132.5 (D) mm
(not including protruding sections)
Panel cutout size 92 × 45 mm
Weight Approx. 600g
■Accessories
- AC input cord*...................................................................................................... 1
- Conversion plug for AC input cord*..................................................................... 1
- Connector for BCD output (when BCO and BSC output option is selected) ....... 1
- Terminator (included only in RS-485 specification)............................................. 1
- Operation manual .................................................................................................. 1
* Included only for AC power supply specifications
