16 Setting Values List
146
Setting Values List
Chapter
16
■Setting mode 1
*1: The decimal place is linked with the decimal place set in setting mode 3.
■Setting mode 2
■Setting mode 3
*1: The decimal place is linked with the decimal place set in setting mode 3.
Name
Default
value
Setting range
Set value
LOCK
Calibration
LOCK
Reference
page
1 HI limit 075.00
-19999 to 99999 *1 ○
P.4 5
2 LO limit 025.00
-19999 to 99999 *1 ○
P.4 5
3 HI/LO limit comparison mode 0
4: Hold
3: MD+NZ
2: NZ
1: MD
0: ALL
○
P.4 7
4 Hysteresis 00.00
0000 to 9999 *1 ○
P.4 8
5 Digital offset 000.00
-19999 to 19999 *1 ○
P.4 3
6 Near zero 001.00
00000 to 99999 *1 ○
P.5 1
7 HH limit 999.99
-19999 to 99999 *1 ○
P.4 5
8 LL limit -199.99
-19999 to 99999 *1 ○
P.4 5
Name
Default
value
Setting range
Set value
LOCK
Calibration
LOCK
Reference
page
1 Moving average filter 030 0 to 1 (OFF), 2 to 999 times
○
P.3 7
2 Analog filter 2
7: 30kHz 6: 10kHz
5: 3kHz 4: 1kHz
3: 300Hz 2: 100Hz
1: 30Hz 0: 10Hz
○
P.3 6
3 Motion detect (time) 1.5 0.0 to 9.9sec.
○
P.3 9
4 Motion detect (range) 05 00 to 99
○
P.3 9
5 Zero tracking (time) 0.0 0.0 to 9.9sec.
○
P.4 0
6 Zero tracking (range) 00 00 to 99
○
P.4 0
7 Hold mode 0
1: Peak hold
0: Sample hold
○
P.5 2
Name
Default
value
Setting range
Set value
LOCK
Calibration
LOCK
Reference
page
1 Set value LOCK 0 1: ON 0: OFF P.66
2 Calibration LOCK 0 1: ON 0: OFF P.35
3 ZERO key valid/invalid 0 1: Invalid 0: Valid P.43
4 HOLD key valid/invalid 0 1: Invalid 0: Valid P.62
5 Min. scale division 0.01
001 to 100 *1 ○
P.3 2
6 Display frequency 3
3: 25 times/sec. 2: 13 times/sec.
1: 6 times/sec. 0: 3 times/sec.
○
P.3 6
7 Decimal place 2
3: 00 . 000 2: 000 . 00
1: 0000 . 0 0: 00000
○
P.3 2
8 Excitation voltage 0 1: 10V 0: 2.5V
○
P.3 1
16Setting Values List
