Unipulse F325 User Manual

147
16 Setting Values List
147
Setting Values List
Chapter
16
■Setting mode 4
*1: The decimal place is linked with the decimal place set in setting mode 3.
*2: The maximum number of times is the set sampling rate.
■Setting mode 5
*1: The decimal place is linked with the decimal place set in setting mode 3.
*3: The setting range is as follows depending on the sampling rate.
3000 times/sec.: 10 to 300Hz, 300 times/sec.: 1.0 to 30.0Hz, 30 times/sec.: 0.1 to 3.00Hz
Name
Default
value
Setting range
Set value
LOCK
Calibration
LOCK
Reference
page
1
RS-485
I/F setting
Baud rate 4
5: 38400bps 4: 19200bps
3: 9600bps 2: 4800bps
1: 2400bps 0: 1200bps
○
P. 78
Length of character 1 1: 8bit 0: 7bit
Parity bit 2
2: Even 1: Odd
0: None
Stop bit 0 1: 2bit 0: 1bit
Terminator 1 1: CR+LF 0: CR
2 RS-485 ID 01 01 to 32
○
P. 78
3 RS-485 transmission delay time 00 00 to 99ms
○
P. 87
4 BCD data update rate 10
10: 3000times/sec.
9: 1000times/sec.
8: 500times/sec. 7: 300times/sec.
6: 100times/sec. 5: 50times/sec.
4: 30times/sec. 3: 10times/sec.
2: 5times/sec. 1: 3times/sec.
0: 1time/sec. *2
○
P.109
5 D/A zero setting 000.00
-19999 to 99999 *1 ○
P.121
6 D/A full scale setting 100.00
-19999 to 99999 *1 ○
P.121
7 D/A output mode 0
3: 20mA (10V) fixed output
2: 4mA (0V) fixed output
1: Not linked with indicated value
0: Linked with indicated value
○
P.122
8 Password 0000 1239: Initialization P.67
Name
Default
value
Setting range
Set value
LOCK
Calibration
LOCK
Reference
page
1 Alarm HI limit 999.99
-19999 to 99999 *1 ○
P. 50
2 Alarm LO limit -199.99
-19999 to 99999 *1 ○
P. 50
3
Output
selection
Output selection 1
(B5)
0
5: DZ response 4: NZ
3: Hold 2: RUN
1: Overload 0: HH
○
P. 44
Output selection 2
(B6)
0
5: DZ response 4: NZ
3: Hold 2: RUN
1: Overload 0: LL
○
P. 44
4 Sampling rate 2
2: 3000times/sec. 1: 300times/sec.
0: 30times/sec.
○
P. 37
5 Digital low-pass filter 0 0 (OFF), 10 to 300 *3
○
P. 38
6 Peak hold selection 0 1: Analog 0: Digital
○
P. 59
7 Hold fix section 0 1: ON 0: OFF
○
P. 60
8 Hold detection wait 0.00 0.00 to 1.00sec.
○
P. 61
9 Hold value renewal timing 0 1: Detection stop 0: Detection start
○
P. 60
