4 Calibration
30
Calibration
Chapter
4
4-2. Actual load calibration procedures
Follow the procedures below for actual load calibration.
4-3. Equivalent input calibration procedures
Follow the procedures below for equivalent input calibration.
(1) Calibration LOCK release
(2) Decimal place setting
3) Equivalent input calibration
(4) Calibration LOCK
(3) Min. scale division setting
3) Equivalent input calibration
(4) Calibration LOCK
(4) Zero calibration
(5) Actual load calibration
(6) Calibration LOCK
Release calibration LOCK prohibiting calibration.
Set the decimal point position.
(Omit if there is no change.)
Set the minimum value of the digital change desired.
(Omit if there is no change.)
Create an unloaded condition (where no force is applied
to a sensor), and set a zero point of a strain gauge type
sensor.
Apply load onto a sensor
and set a span (gain) point of the strain gauge type
sensor.
Switch calibration LOCK ON to avoid operational errors.
Release calibration LOCK prohibiting calibration.
Set the decimal point position.
(Omit if there is no change.)
Set the minimum value of the digital change desired.
(Omit if there is no change.)
Enter a rated output value and zero point of a strain
gauge type sensor.
Switch calibration LOCK ON to avoid operational errors.
(1) Calibration LOCK release
(2) Decimal place setting
(4) Calibration LOCK
(3) Min. scale division setting
(4) Equivalent input calibration
(5) Calibration LOCK
