15 Specifications
135
Specifications
Chapter
15
■Display section
Display unit Numbers are displayed by a 7-segment green LED with a character
height of 15mm (5-digit)
Numerical value: 5 digits ±
Indicated value: -19999 to 99999
Decimal point: Display point is selectable
(0.000, 00.00, 000.0, 0000)
Display items Status display: Red 3φLED HI, LO, PEAK, HOLD
Green 3φLED OK
Display frequency: Selectable from 3, 6, 13, 25 times/sec.
■Setting section
Key switch
Set items Calibration: Zero calibration/Span calibration (actual load calibration,
equivalent input calibration)
Setting mode 1 HI limit, LO limit, HI/LO limit comparison mode, hysteresis,
digital offset, near zero, HH limit, LL limit
Setting mode 2 Moving average filter, analog filter, motion detect (time),
motion detect (range), zero tracking (time), zero tracking (range),
hold mode
Setting mode 3 Set value LOCK, calibration LOCK, ZERO key valid/invalid,
HOLD key valid/invalid, min. scale division, display frequency,
decimal place, excitation voltage
Setting mode 4 RS-485 I/F setting, RS-485 ID, RS-485 transmission delay time,
BCD data update rate, D/A zero setting, D/A full scale setting,
D/A output mode, password
Setting mode 5 Alarm HI limit, alarm LO limit, output selection, sampling rate,
digital low-pass filter, peak hold selection, hold fix section,
hold detection wait, renewal timing of hold value
Setting mode 6 RS-485 communication type, RS-232C communication type,
RS232C I/F setting, BCD output mode, BCD B9 output selection,
automatic printing, hold value printing
Setting mode 7 I/O input check, I/O output check, BCD input check, BCD output check,
RS-232C check, RS-485 check, interface, option type, version
FNC GAIN CAL ZERO HOLD
(5 keys)
(+/-) ( ▲ )(▼ ) ( ) ( )
▲
