15 Specifications
138
Specifications
Chapter
15
■Options
BCD parallel data output interface
Output can be selected from sink type (BCO) or source type (BSC) (to be specified at the time of
order).
Output rate: Selectable from1 time/sec., 3 times/sec., 5 times/sec., 10 times/sec., 30 times/sec.,
50 times/sec., 100 times/sec., 300 times/sec., 500 times/sec., 1000 times/sec.,
3000 times/sec.
However, the maximum number of times is the set sampling rate.
BCD data hold and positive logic / negative logic selection is possible.
<Sink type (BCO)>
- Output
Output format Sink type
The output transistor should be turned ON when the signal is ON.
When connecting input units such as PLC, connect a plus common type.
Rated voltage DC30Vmax
Rated current 50mAmax
- Input
Input format No-voltage contact input (built-in power supply voltage DC5V)
Relays, switches, and transistors can be connected.
Signals are input by the short-circuit and open-circuit between input
terminals and the common terminal.
Use a sink type when connecting transistors.
Short circuit flow Approx. 6mA
<Source type (BSC)>
- Output
Output format Source type
Output transistor should be turned ON when the signal is ON.
When connecting input units such as PLC, connect a minus common type.
Rated voltage DC30Vmax
Rated current 20mAmax
- Input
Input format Minus common input
Relays, switches, and transistors can be connected.
Signals are input by the short-circuit and open-circuit between input
terminals and the common terminal.
Use a source type when connecting transistors.
Rated voltage DC27.6Vmax
ON condition DC9V or more (load current at DC24V = approx. 5mA)
OFF condition DC3V or less
