Unipulse F701+ User Manual

2
1 Before Getting Started
2
Before Getting Started
Chapter
1
Warning
● Be sure to install and fix the product to the control panel and so forth. In doing so, install a
breaker so that an operator can turn power OFF immediately, and place an appropriate
indication showing the breaker installation.
● Prepare a safety circuit outside the F701+ so that the entire system functions safely.
● Be sure to contact our sales representative before use if the F701+ will be use
d in the
following situations:
- If the product is used in an environment not described in the operation manual;
- If the product is used in a way that may have a substantial effect on medical devices,
transportation equipment, entertainment devices, safety devices, etc.
● Do not disassemble, repair or alter the F701+.
● Do not install the product in the following environments:
- Locations with corrosive
gases or combustible gases;
- Locations over which water, oil, or chemicals splash.
● Do not connect commercial power supply directly to the signal I/O terminal.
● Be sure to perform class D grounding when installing the main unit.
● The rating of the AC cable included is AC125V, 10A. Prepare a separate AC cable if the
product is used at a voltage higher than the rating or is used overseas.
● Be sure to c
heck that the power is off before the following actions:
- Removal and installation of optional connectors and so forth;
- Wiring and connection of cables to a terminal block;
- Connection to frame grounding terminals.
● Be sure to check signal names and pin assignment numbers before connecting to the signal
I/O terminal in order to wire cables properly.
● No connection is necessary for unused terminals.
●
Be sure to check the wiring and so on carefully before turning the power on.
● Use power supply voltage and load within the specified range and rating.
● Do not damage the power cords. Fire or electric shock may occur.
● Do not touch the terminal while power is on. This may cause electric shock and malfunction.
● Do not open the main unit cover. Contact us for inspection and/or repair of internal parts.
● T
urn power off and unplug power cable immediately if smoke, abnormal smell, or abnormal
noise is detected.
Events that may cause death or severe injury to persons
in cases of misuse.
Design warning
Installation warning
Wiring warning
Startup/maintenance warning

Unipulse F701+ Specifications

General

Brand	Unipulse
Model	F701+
Category	Measuring Instruments
Language	English
