Chapter 6 ______________________________________________________________ Maintenance
VAISALA ______________________________________________________________________ 227
NOTE
It is important for the alignment procedure, that no significant
atmospheric visibility variations occur during the procedure. For this
reason, it is recommended to do the procedure in weather conditions that
are stable without precipitation and with visibility above 10 km.
To make sure that the transport protection in the transmitter and receiver
measurement unit have been removed, the user has to give a
confirmation. See Figure 129 below and the example below:
HAS THE TRANSPORT PROTECTION IN THE T/R OPTIC UNITS BEEN
REMOVED? (yes/no) :
To confirm, type yes<CR>.
To abort the action, type no<CR>.
As the current position of all axes will be lost, the user has to confirm the
movement to the mid position for all axes. See the example below:
Move Optics To Mid Position. Are You Sure? (yes/no):
To confirm, type yes<CR>.
To abort the action, type no<CR>.
Now all axes are moved to the mid position, one by one. Indication of the
process is given on the left of the menu.
0401-113
Figure 129 Moving the Axes to Mid-position
To get an impression of the main receiver signal value without reading
the display, an acoustic signal is generated at the transmitter and receiver
location.
