4) Adjust the PHANTOM JIG ASS’Y level by using BUBBLE LEVEL and three ALIGN PINs.
5) Put the CT NUMBER CHECK PHANTOM on the PHANTOM JIG ASS’Y.
6) Run Console Software and click CBCT to go into CBCT mode.
BUBBLE LEVEL
ALIGN PIN
ID Number
CT NUMBER CHECK PHANTOM
