Smart Plus (PHT-35LHS)
Technical Manual
VT-TECH-Smart Plus-001
COPYRIGHT© 2018 VATECH.
Noise and Homogeneity
1) Run VAKCAP.exe.
Path: C:\VCaptureSW\Acquisition\Pano\WidePano folder
2) Click the Panorama tab and click V Pan to open View 16.
3) Click and select Capture.raw to open the captured image.
Capture.raw path: C:\VCaptureSW\Acquisition\Pano\WidePano\PAN
4) Select 1 in the Z box and type 40 in the M box.
5) Type 800,800 in the X, Y box and make sure that ave and dev values meet the standard.
6) Type 2000,800 in the X, Y box and make sure that ave and dev values meet the standard.
