Smart Plus (PHT-35LHS)
Technical Manual
VT-TECH-Smart Plus-001
165 / 188
COPYRIGHT© 2018 VATECH.
ALL RIGHTS RESERVED
<===== P axis B'd (G2) =====>
Version: 9.00.04
▶MAIN MCU BOARD Firmware Version Information
<=========================>
0035=>(spm_PXST_xxxx) PANO X COUNT (1160 = 11.60cm)
▶PANO X axis position value set(Initial-Value : 1003 (1~9999))
0410=>(spm_PYST_xxxx) PANO Y COUNT (1160 = 11.60cm)
▶PANO Y axis position value set(Initial-Value : 0510 (1~9999))
0038=>(spm_AXST_xxxx) ARCT X COUNT (1160 = 11.60cm)
▶ ARCT X axis position value set(Initial-Value : 1003 (1~9999))
0010=>(spm_AYST_xxxx) ARCT Y COUNT (1160 = 11.60cm)
▶ ARCT Y axis position value set(Initial-Value : 0160 (1~9999))
0600=>(spm_HXST_xxxx) CEPH X COUNT (1160 = 11.60cm)
▶ CEPH X axis position value set(Initial-Value : 0620 (1~9999))
1314=>(spm_HYST_xxxx) CEPH Y COUNT (1160 = 11.60cm)
▶ CEPH Y axis position value set(Initial-Value : 0180 (1~9999))
~~~~~~~~~~~~~~~~~~~~~~~~~~~~
0830=>(spm_HFST_xxxx) PANO HALF_COUNT
▶Rotator Unit Position Reference Location Value in PANO Mode (Initial-Value : 1200 (1~9999))
0830=>(spm_ACHF_xxxx) ARCT_HALF_COUNT
▶ Rotator Unit Position Reference Location Value in ARCT Mode (Initial-Value : 1200 (1~9999))
0830=>(spm_CPHF_xxxx)CEPH_HALF_COUNT
▶Rotator Unit Position Reference Location Value in CEPH Mode (Initial-Value : 3900 (1~9999))
~~~~~~~~~~~~~~~~~~~~~~~~~~~~
00001=>(spm_POFS_xxxxx)ROTATOR_OFFSET_COUNT
▶Rotator Unit Starting Position Reference Location Value in PANO Mode (Initial-Value : 10400
(1~19999))
(dyyyy : d direction(1 or 0), yyyy distance)
00001=>(spm_COFS_xxxxx)ARCT_ROTATOR_OFFSET_COUNT
▶Rotator Unit Starting Position Reference Location Value in ARCT Mode (Initial-Value : 00001
(1~19999))
(dyyyy : d direction(1 or 0), yyyy distance)
~~~~~~~~~~~~~~~~~~~~~~~~~~~~
0000=>(spm_PSTY_000x)PANO SEQUENCE MODE IS?
0: 200Hz(Normal Pano) type, 400Hz(Fast Pano /*child349Hz) (default)
1: 400Hz(Normal Pano) type, 400Hz(Fast Pano /*child349Hz )
2: 200Hz(Normal Pano) type, 300Hz(Fast Pano /*child300Hz)
▶Panorama sequence type setting
0000: Smart Plus(default)
0002: Green 16/18
~~~~~~~~~~~~~~~~~~~~~~~~~~~~
0000=>(spm_IPTY_000x)INSIGHT_PANO_TYPE_IS?
0:200Hz(Insight Pano)(default)
1: 150Hz(Insight Pano)
2: xxxHz(Insight Pano)
▶Insight Panorama sequence type setting
0000: 200Hz(default)
0001: 150Hz
0002: NC
~~~~~~~~~~~~~~~~~~~~~~~~~~~~
0005=>(spm_CISC_000x)CEPH MODE IS?
0: Disable
1: Scan Ceph (cone beam ceph)
3: One-Shot Ceph (R-Troy, Large FOV)
4: One-Shot Ceph (TOK-Troy, Small FOV)
5: Scan Ceph (Table Control)
