Smart Plus (PHT-35LHS)
Technical Manual
VT-TECH-Smart Plus-001
166 / 188
COPYRIGHT© 2018 VATECH.
ALL RIGHTS RESERVED
▶CEPH Activation Setting
0000: CEPH mode Inactivated (PANO Only model) (default)
0001: SCAN CEPH mode Activated
0003: One-Shot CEPH mode Activated (R-Troy)
0004: One-Shot CEPH mode Activated (TOK-Troy)
0005: Scan Ceph (Table Control)
~~~ceph sensor start position offset~~~
1800=>(spm_UATT_xxxx)CEPH_TABLE_A_START_OFFSET_COUNT (0165 = 16.5cm).
▶CEPH sensor Start Offset Value - A mode(Lateral mode)
0240=>(spm_UBTT_xxxx)CEPH_TABLE_B_START_OFFSET_COUNT (0165 = 16.5cm).
▶CEPH sensor Start Offset Value - B mode(PA mode)
1800=>(spm_UCTT_xxxx)CEPH_TABLE_C_START_OFFSET_COUNT (0165 = 16.5cm).
▶CEPH sensor Start Offset Value - C mode
0240=>(spm_UDTT_xxxx)CEPH_TABLE_D_START_OFFSET_COUNT (0165 = 16.5cm).
▶CEPH sensor Start Offset Value - D mode
1800=>(spm_UETT_xxxx)CEPH_TABLE_E_START_OFFSET_COUNT (0165 = 16.5cm).
▶CEPH sensor Start Offset Value - E mode
0240=>(spm_UFTT_xxxx)CEPH_TABLE_F_START_OFFSET_COUNT (0165 = 16.5cm).
▶CEPH sensor Start Offset Value - F mode
1800=>(spm_UGTT_xxxx)CEPH_TABLE_G_START_OFFSET_COUNT (0165 = 16.5cm).
▶CEPH sensor Start Offset Value - G mode
0240=>(spm_UHTT_xxxx)CEPH_TABLE_H_START_OFFSET_COUNT (0165 = 16.5cm).
▶CEPH sensor Start Offset Value - H mode
~~~1st collimator: ceph table velocity modify parameter~~~
0000=>(spm_CLVC_xxxx)CL_VELO_COMP : 1st collimator velocity-period offset
▶Collimator Left Velocity Calibration value(Initial-Value : 0 (1~9999))
0000=>(spm_CRVC_xxxx)CR_VELO_COMP : 1st collimator velocity-period offset
▶Collimator Right Velocity Calibration value(Initial-Value : 0 (1~9999))
0000=>(spm_CLVA_xxxx)CL_VELO_ACCEL_COMP: 1st collimator accel-period offset
▶Collimator Left Acceleration Calibration value(Initial-Value : 0 (1~9999))
0000=>(spm_CRVA_xxxx)CR_VELO_ACCEL_COMP : 1st collimator accel-period offset
▶Collimator Right Acceleration Calibration value(Initial-Value : 0 (1~9999))
~~~~~~~~~~~~~~~~~~~~~~~~~~~~
0160(HZ)=>(spm_CFRQ_xxxx)CEPH PULSE HZ SET
▶CEPH Sensor frequency set (Initial-Value : 0160 (1~9999))
1730=>(spm_XRFA_xxxx)CEPH_REF_X1_START POSITION (1730 = 17.3cm)
