[SPM_CAST_#####] Set position value of 1-Axis Collimator (CEPH mode)
Initial-Valu : 10600 (1~3455, 10000~10655)
##### = dyyyy (d: Direction, yyyy: Distance) ex. 00100 = Change 1mm
[SPM_CAS?] Request “CAST” Parameter value
[SPM_CDST_#####] Set position value of 1-Axis Collimator (One-Shot CEPH mode, OPEN
position) (Also move to OPEN position in PANO mode)
Initial-Value: 5 (1~3455, 10000~10655)
[SPM_CDS?] Request “CDST” Parameter value
[SPM_CEST_#####] Set position value of 1-Axis Collimator (CT Filter)
Initial-Value: 3455 (1~3455, 10000~10655)
[SPM_CES?] Request “CEST” Parameter value
 Serial Number Setting Command
Command Description
[SPM_SNUM_#########] Set Serial Number
Ex) SN:047-0123 = Enter [SPM_SNUM_0470123]
[SPM_SNU?] Request Serial Number
 PANO Align & Calibration Setting Command
Command Description
[SPM_HFST_####] Set Lamp position of PANO mode
Initial-Value: 1200 (1~9999)
[SPM_HF?_] Request current “HFST” Parameter value
[SPM_POFS_#####] Set Capture starting position of Rotating Unit in PANO mode
(##### = If the first digit is 1, it means clockwise, and 0 means counter-
clockwise)
Initial-Value: 10400 (1~19999)
[SPM_PO?_] Request current “POFS” Parameter value
[SPM_PXST_####] Set X axis Reference position of PANO mode
Initial-Value: 1003 (1~1999))
#### = dyyy (d: Direction, yyy: Distance) ex. 0234 = 2.34cm
[SPM_PX?_] Request current “PXST” Parameter value
[SPM_PYST_####] Set Y axis Reference position of PANO mode
Initial-Value: 0510 (1~1999)
#### = dyyy (d: Direction, yyy: Distance) ex. 0234 = 2.34cm
[SPM_PY?_] Request current “PYST” Parameter value
 CEPH Align & Calibration Setting Command
Command Description
[SPM_CPHF_####] Set Tilting position of Rotating Unit in CEPH mode
(Initial-Value: 3900 (1~9999))
