[SPM_PHF?] Request current “CPHF” Parameter value
[SPM_HXST_####] Set X axis Reference position of CEPH mode
Initial-Valu : 0620(1~1999)
#### = dyyy (d: Direction, yyy: Distance) ex. 0234 = 2.34cm
[SPM_HX?_] Request current “HXST” Parameter value
[SPM_HYST_####] Set Y axis Reference position of CEPH mode
Initial-Value: 0180(1~1999)
#### = dyyy (d: Direction, yyy: Distance) ex. 0234 = 2.34cm
[SPM_HY?_] Request current “HYST” Parameter value
[SPM_UATT_####]
Set Capture starting position in Lateral mode of CEPH Sensor
motor
(Image Quality: High Resolution, Initial-Value: 0100 (1~9999))
Ex) 0117 = 11.7cm
[SPM_UAT?] Request current “UATT” Parameter value
[SPM_UBTT_####] Set Capture starting position in PA, SMV, Waters' View mode of
CEPH Sensor motor
(Image Quality: High Resolution, Initial-Value: 0165 (1~9999))
Ex) 0165 = 16.5cm
[SPM_UBT?] Request current “UBTT” Parameter value
[SPM_UCTT_####] CEPH sensor Motor Capture starting position in the following mode:
Full Lateral, High Quality
[SPM_UDTT_####] CEPH sensor Motor Capture starting position in the following mode:
Carpus, High Quality
[SPM_UETT_####] CEPH sensor Motor Capture starting position in the following mode:
Lateral, Green
[SPM_UFTT_####] CEPH sensor Motor Capture starting position in the following mode:
PA/SMV/Waters' View, Green
[SPM_UGTT_####] CEPH sensor Motor Capture starting position in the following mode:
Full Lateral, Green
[SPM_UHTT_####] CEPH sensor Motor Capture starting position in the following mode:
Carpus, Green
[SPM_XRFA_####] Set Reference position of CEPH Sensor
(Initial-Value: 1730 (1~9999))
[SPM_XFA?] Request current “XRFA” Parameter value
[SPM_CFRQ_####] Set Frequency of CEPH Sensor
(Initial-Value: 0160 (1~9999))
[SPM_CFR?] Request current “CFRQ” Parameter value
[SPM_CCTM_####] Set Scan Time of CEPH mode
Ex) 1350 = 13.50 sec
[SPM_CCT?] Request current “CCTM” Parameter value
