9) Type 95 in the T box. Select S in the M box.
10) Make sure that the result meets the CBCT Left/Right collimator-alignment standard values.
Position Alignment Standards
(Red pixels covered by collimator)
Left 1 ~ 2 pixels
Right 1 ~ 2 pixels
Left
Right
