Vatech Smart Plus PHT-35LHS - CBCT Rotator Position Alignment

Smart Plus (PHT-35LHS)
Technical Manual
VT-TECH-Smart Plus-001
63 / 188
COPYRIGHT© 2018 VATECH.
ALL RIGHTS RESERVED
10) Type 75 in the T box. Select S in the M box.
11) Make sure that the result meets the CBCT Top/Bottom collimator-alignment standard.
Position Permitted value
(Red pixels covered by collimator)
Top 10 ~ 15 pixels
Bottom 10 ~ 15 pixels
Top
Bottom
