Veeder-Root TLS2P - Alpha Keypad Screen

System Setup Screens Alpha Keypad Screen
11
Alpha Keypad Screen
Legend for numbered boxes
1
2
3
4
5 6 7 8 9
10
SAVE
ENTER: STATION HEADER 1
JOHNS MOBIL
1 Displays Title of data to be entered.
2 Data Entered Window displays data entered.
3 Alpha keypad buttons - touch a character button to
place that character in the data entered window (2).
4 Save button - touch to accept entered data and close
Screen.
5 Cancel button - touch to cancel any entry and close
Screen.
6 Cursor left button - touch to move the cursor one
position left in the Data Entered Window (2).
7 Cursor right button - touch to move the cursor one
position right in the Data Entered Window (2).
8 Backspace delete button - touch to delete character in
cursor.
9 Number keypad button - touch to display the Numeric
Keypad Screen.
10 Clear button - touch to clear contents of Data Entered
Window (2).
