Reports Inventory Report (US Units and Non-Density Probe)
65
Inventory Report (US Units and Non-Density Probe)
To see the inventory report(s) for any other tank touch the inventory report button for that tank at the bottom of the
screen. To view the shift inventory report for the tank touch the Shift Inventory button (item 1 in the screen above). To
view the stick height (if enabled), touch the Delta Stick button (item 2 in the screen above). To view the Inventory Log
report for the selected tank, touch the Inventory Log Report button (item 3 in the screen above).
EXAMPLE REPORT PRINTOUT - INVENTORY REPORT WITH TC VOLUME
T 1:REGULAR UNLEADED
TANK VOLUME TC VOLUME ULLAGE HEIGHT WATER TEMP
1 5329 5413 4500 48.8 0.0 37.3
2 5329 5413 4500 48.8 0.0 37.3
EXAMPLE REPORT PRINTOUT - SHIFT INVENTORY REPORT WITH TC VOLUME
T 1:REGULAR UNLEADED
TANK PRODUCT
1 REGULAR UNLEADED VOLUME TC VOLUME ULLAGE HEIGHT WATER TEMP
SHIFT 1 STARTING VALUES 8518 8492 1482 76.26 0.0 64.7
ENDING VALUES 8518 8492 1482 76.26 0.0 64.7
DELIVERY VALUE 0
TOTALS 0
SHIFT 2 STARTING VALUES 8518 8492 1482 76.26 0.0 64.7
ENDING VALUES 8518 8492 1482 76.26 0.0 64.7
DELIVERY VALUE 0
TOTALS 0
Inventory Report Notes
• The TC Volume and temperature columns are printed only for the probes in the system that have temperature
measurement capability.
• If system setup parameter Print TC Volumes is set to NO, the TC Volume and temperature columns are not
printed.
• The water column is printed only for probes in the system that have water measurement capability.
01-01-2000
12:00 AM
ALL FUNCTIONS NORMAL
123456
2
3
1
5329 GAL
(5413 GAL TC)
72 IN
37.3 F
WATER 0.0 IN
