Veeder-Root TLS2P - Get TCPIP Parameters Confirmation Dialog

System Setup Screens Get TCPIP Parameters Confirmation Dialog
30
Get TCPIP Parameters Confirmation Dialog
Legend for numbered boxes
1 2
2
The Get TCPIP Parameters dialog box (upper screen)
displays when you touch the GET button on the TCPIP
setup screen (see page 28).
1 OK button - touch to have the TLS2P get the TCPIP
parameters (280 - 283) saved in the Lantronix server.
The lower screen displays while the TLS2P is
updating the TCPIP.
2 Cancel button - touch to cancel the TCPIP Get
parameters request and return to the TCPIP setup
screen.
