Communication Interfaces
VTK-TR-BA-072e-1 - User Manual MDS 358X Series
89
5 ADJUST:START
Description:
Sending this command causes the adjust to be executed at once. This
procedure checks on the position of the nozzle insert with respect to the
tappet. It is required during each initial start-up and after replacing the
nozzle unit.
For further information read paragraph 8.2.3, page 117.
Example:
Input:
ADJUST:START
Result:
The adjust is initiated.
Return:
Adjust Screw OUT Press Enter
6 ADJUST:OFFSET:?
Description:
This command gives the current value of the adjust offset (see
paragraph 7.12, page 75).
The value can be between -5 and 5. The value 0 means, the adjust offset is
deactivated.
Example:
Input:
ADJUST:OFFSET:?
Result:
The current value of the adjust offset is returned.
Return:
5
7 ADJUST:OFFSET:<offset value>
Description:
This command sets the value for the adjust offset (see paragraph 7.12,
page 75).
You can enter integer values between -5 and 5. With 0 you deactivate the
adjust offset.
Example:
Input:
ADJUST:OFFSET:5
Result:
The value of the adjust offset is set (here: to 5).
Return:
OK
8 ADJUST:CALIBRATION:?
Description:
This command gives the status of the (remote) adjust and the current
adjust value. The response to this command contains seven numerical
values. You can ignore the first six parameters limit at 0 %, limit at 100 %,
difference, reference value, last mean value and total value). They are only
there for our support, if there is an error with the (remote) adjust.
The last parameter sent is the adjust value in percent. Be aware that the
given value is the actual percentage value, multiplied by 10. Therefore, a
given value of 8 represents an adjust value of 0.8 %.
Example:
Input:
ADJUST:CALIBRATION:?
Result:
The status of the (remote) adjust is given, including the
current adjust value.
Return:
151285, 47623, 103662, 150836, 108654, 42182, 8
9 ADJUST:CALIBRATION:ON
Description:
This command activates the adjust, so that you can perform it as a remote
adjust.
Example:
Input:
ADJUST:CALIBRATION:ON
Result:
The adjust is activated.
Return:
Adjust ON
