iVent201 Operator's Manual
155
Table 4.1 Default Start Parameters for Volume Ventilation for 10 kg to 70 kg
Table 4.2 Alarm Default Parameters for Volume Ventilation for 10 kg to 70 kg
Weight (kg) Alarm
Parameter
10 15 20 30 40 50 60 70+
High Pressure
(cmH
2
O)
23 25 30 33 35 40 40 40
High Rate
(bpm)
40 35 30 30 30 30 30 30
Low Rate
(bpm)
10 10 10 8 6 6 6 6
High Min Vol.
(LPM)
5 7 10 14 17 20 24 24
Low Min Vol.
(LPM)
1 1 2 2 3 3 4 4
The following alarms remain constant for all weights:
Low Pressure 5 cmH
2
O
Apnea Time 20 Sec
High FiO
2
Set FiO
2
Value + 20% (Factory Setting 80%)
Patient Weight bpm
Rate
Tidal Volume Max. Pressure
(P
Limit
)
(kg) (lb) (bpm) (mL) (cmH
2
O)
10 22 30 100 18
15 33 25 150 20
20 44 20 200 25
30 66 18 300 28
40 88 16 400 30
50 110 14 500 35
60 132 12 600 35
70+ 154 12 700 35
