iVent201 Operator's Manual
177
The Home Care display only shows the essential data.
Figure 4.72 The Home Care Display
The pulse SpO
2
box is also available also on the Monitor
display.
To display the SpO2 box on the Monitoring screens:
• Select the SPO2 button on the lower left side
of the screen.
The SpO2 box appears on right side of the screen.
Figure 4.73 The pulse Oximetery box in the Home Care Display
