The display, shown in Figure 3-59, shows a chart that is split into three columns,
which shows the information to be identified.
• The DATA COLUMN lists the Video metadata parameter.
• The PRESENT column has two states: No data detected (blank box) and Data
Detected (indicated as present).
• The LOCATION/INFO column displays the location information from the
appropriate specification when it is detected.
Table 3-51. Sample Video Metadata Pane List
Data Present Location/Info
10/8 BIT VIDEO Present 10—bit
CC-1 (608) Present LINE 21
CC-2 (608)
CC-3 (608) Present LINE 21
CC-4 (608)
T-1 (608)
T-2 (608)
T-3 (608)
T-4 (608)
XDS (608)
DTVCC (708)
DVB TELETEXT
DVB SUBTITLES Present LINE 23
WSS
V CHIP
VITC
AUDIO PRESENCE EMBEDDED 1, 2, 3, 4
The second page consists of Video Indexing information for Class 1 (title only), as
shown in Table 3-52.
Table 3-52. Sample Video Index Pane (TVM-VTM-3GB only)
Data Location/info
VIDEO INDEX CLASS 1
STANDARD/ASPECT RATIO 625/50 4×3
GAMUT RGB
SAMPLING 4:0:0
PAN PIXELS: -305.0000
TILT LINES: -281.75
ZOOM LINES: +563.5
To Next Page
