Global Setup Menu Functions
TVM Series Installation and Operation Handbook 141
Copyright © 2008, Harris Corporation
Table 4-2. Video Format Menu
Selection Selection Option Selection Option
OFF - ENABLE DUAL LINK C-D
ON -
INPUT A Rename Screen (Rename and
select ACCEPT or CANCEL)
SOURCE ID
INPUT B Rename Screen (Rename and
select ACCEPT or CANCEL)
OPTION C Rename Screen (Rename and
select ACCEPT or CANCEL)
OPTION D Rename Screen (Rename and
select ACCEPT or CANCEL)
Table 4-3. Waveform Setup Menu
Selection Selection Option
VOLTS (Default) DIGITAL WAVEFORM GRATICULE
PERCENT
OFF NTSC PEDESTAL
ON (7.5 IRE)
UNITS PAL WAVEFORM SCALE
VOLTS (Default)
OFF
SLOW
DC RESTORE (Only available with
TVM-OPT ACV-2 option)
FAST (Default)
WAVEFORM INTENSITY 25% TO 200% (100% is NORMAL)
WAVEFORM CONTRAST 25% TO 200% (100% is NORMAL)
PERSISTENCE NORMAL 1 TO 6 & INFINITE
(NORMAL is Default)
ATTACK 9 to 15 (NORMAL is 9), and MAX (16)
(NORMAL is Default)
OFF ERROR HIGHLIGHTING
ON
Table 4-4. Eye Pattern Setup Menu
Selection Selection Option
0 TO 1.0 UI (Default)
0 TO 0.2 UI
0 TO 3700 ps
JITTER DISPLAY TYPE
0 TO 740 ps
EYE INTENSITY 25% TO 200% (100% is NORMAL)
EYE CONTRAST 25% TO 200% (100% is NORMAL)
