Global Setup Menu Functions
140 TVM Series Installation and Operation Handbook
Copyright © 2008, Harris Corporation
Table 4-2. Video Format Menu
Selection Selection Option Selection Option
AUTODETECT (Default) -
1080i/60 -
1080i/59.94 -
1080i/50 -
VIDEO D FORMAT
1080p/60
(TVM-VTM-3GB only) -
1080p/59.94 (TVM-VTM-3GB only) -
1080p/50 (TVM-VTM-3GB only) -
1080p/30 -
1080p/29.97 -
1080p/25 -
1080p/24 -
1080p/23.98 -
1080p/30sF -
1080p/29.97sF -
1080p/25sF -
1080p/24sF -
1080p/23.98sF -
720p/60 -
720p/59.94 -
720p/50 -
720p/30 -
720p/29.97 -
720p/24 -
720p/23.98 -
625/50 -
525/59.94 -
NTSC (Only available with inputs C and
D when the TVM-VTM ACV-2 option)
-
PAL
(Only available with inputs C and D
when the TVM-VTM ACV-2 option)
-
AUTO/10 bit YCBCR (Default)
4:2:2
-
10 BIT YCBCR 4:4:4 -
10 BIT RGB 4:4:4 -
12 BIT YCBCR 4:4:4 -
12 BIT RGB 4:4:4 -
VIDEO D STRUCTURE
12 BIT YC
BCR 4:2:2 -
