TVM Series Installation and Operation Handbook 1
Copyright © 2008, Harris Corporation
Section 1 ♦ Introduction
Product Description
The Videotek TVM Series multi-format, 3GB/s/HD-SDI/SD-SDI video monitoring
unit is the most advanced, versatile, and intuitive 3GB/s/HD-SDI/SD-SDI monitoring
instrument available today. With 100% digital signal processing technology; integral,
high-resolution, XGA TFT color LCD display; the TVM Series provides an accurate
and stable user customizable display of multiple Waveform, Vector, Gamut, Audio,
Picture, Relative Timing, Alarm Status, and Data Analyzer functions in quadrant or
full-screen views. Quick setup and parameter changes are possible with direct access to
display functions and screen location, 16 presets, context sensitive pop-up menus, and
an intuitive navigation system.
The TVM Series units can be completely customized. The TVM-ASX (console that
contains the system board) is capable of analyzing HD, SD, and Analog formats. The
TVM-10 or TVM--40 Graphics Display Engine can be loaded into the unit. Any two of
the TVM video input boards can be loaded into the unit. Any one TVM-A3 Audio
Options can be loaded into the unit.
The TVM Series features extensive audio and video alarm capabilities including peak
level reporting, video and Dolby
®
metadata, EIA-608 and 708 closed caption
detection/alarm display, and teletext and XDS processing. All real-time signal alarms
have user adjustable limits, time stamps from LTC, or DVITC and an internal clock,
and logging may include an active link to a frame capture where applicable. Remote
interfaces include 10/100BaseT Ethernet and plug-n-play USB port (supporting storage
and recall of presets, frame-capture transfer, and keyboard integration). The TVM
Series instruments are digital instruments with all-digital architecture; therefore, no
periodic calibration is required.
The TVM Series seamlessly integrates into any broadcast, post-production, camera
maintenance, satellite or cable facility, and is the ultimate choice for quality control,
troubleshooting, or compliance checking applications.
*
US Patents 6,069,607, 6,532,024, and 6,828,981. UK Patent 2,330,475. Other US and foreign patents pending.
Standard Features
• Dual HD-SDI/SD-SDI inputs with auto detection (TVM9100PKG or
TVM9140PKG)
• Dual 3GB/s/s/HD-SDI/SD-SDI inputs with auto detection (TVM9140PKG-3GB)
• Display multiple inputs simultaneously (TVM9140PKG) (TVM-40)
• Pixel Locator/Data Word Analyzer/Camera Maintenance (TVM9140PKG)
(TVM-VTM-AAP) or (TVM-40)
• Dual Link (4:4:4) Y, CB, CR
• A/B Parade and Overlay
• Closed Caption detection, alarm, and display (608 and 708)
