General Operation
40 TVM Series Installation and Operation Handbook
Copyright © 2008, Harris Corporation
NOTE: The component sequence selections are dynamically dependent on the SD or HD
format selection. The component selections will only be shown when the component formats
are selected.
Table 3-7. Waveform (Analog) Menu Structure
Selection Selection Option
FLT (FLAT)
LP (LOW PASS)
CHR (CHROMA )
F/LP (FLAT & LOW PASS)
COMPOSITE FILTER
R-Y (TVM-VTM- ACV-2
OPTION ONLY)
PARADE PARADE/OVERLAY
OVERLAY
CENTER WAVEFORM ENTER
WAVEFORM SETUP Press ENT
Table 3-8. Waveform (SD-SDI) Menu Structure
Selection Selection Option Selection Option
FLAT (FLT) -
LOW PASS (LP) -
CHROMA (CHR) -
COMPOSITE FILTER (for
digital formats)
F/LP (FLAT & LOW PASS) -
FLAT -
LOW PASS -
COMPONENT FILTER
BOW (BOWTIE) -
PARADE - PARADE/OVERLAY
OVERLAY -
CMPST (COMPOSITE) -
YCBCR -
RGB -
SD FORMAT
YRGB -
BLANK ALL -
SHOW EAV/SAV -
BLANKING
SHOW ALL -
If CMPST is selected - Not
Available
-
ON If YCBCR is selected (Y, C
B
,
C
R
)
OFF
ON
COMPONENT SEQUENCE
(related to SD FORMAT
selection)
If RGB is selected (R, G, B)
OFF
To Next Page
