Global Setup Menu Functions
142 TVM Series Installation and Operation Handbook
Copyright © 2008, Harris Corporation
Table 4-4. Eye Pattern Setup Menu
Selection Selection Option
PERSISTENCE NORMAL, 1 to 6, & INFINITE
(NORMAL is Default)
ATTACK LOW (1), 2 to 15 (NORMAL is 9), and
MAX (16) (LOW is Default)
Table 4-5. Vector Setup Menu
Selection Selection Option
NORMAL (Default) PAL OVERLAY
OVERLAY
OFF (Default) SDI I/Q LINES
ON
VECTOR INTENSITY 25% TO 200% (100% is NORMAL)
VECTOR CONTRAST 25% TO 200% (100% is NORMAL)
PERSISTENCE NORMAL, 1 TO 6, & INFINITE
(NORMAL is Default)
ATTACK LOW (1), 2 to 15 (NORMAL is 9), and
MAX (16) (LOW is Default)
Table 4-6. Gamut Setup Menu
Selection Selection Option
GAMUT INTENSITY 25% TO 200% (100% is NORMAL)
GAMUT CONTRAST 25% TO 200% (100% is NORMAL)
PERSISTENCE NORMAL, 1 TO 6, & INFINITE
(NORMAL is Default)
SINGLE COLOR COLOR PLOT
RGB (Default)
DATA ERROR PERSISTENCE NORMAL, 1 TO 6, & INFINITE
(NORMAL is Default)
Table 4-7. Picture Setup Menu
Selection Selection Option Selection Option
UPPER LEFT
UPPER RIGHT
LOWER LEFT
LOWER RIGHT
UPPER LEFT PANE
OFF (Default)
UPPER LEFT
UPPER RIGHT
LOWER LEFT
THUMBNAIL
UPPER RIGHT PANE
LOWER RIGHT
