Installation
TVM Series Installation and Operation Handbook 15
Copyright © 2008, Harris Corporation
Table 2-1. Parts Required to Rack Mount the TVM Using the DRC-2A
Key Item Number Quantity Description
9 831064 4(*) #8–32×1/2-in. PP screws
10 831114 4(*) #8 Ext. tooth lock washers
11 831019 4 (2 each side) Nylon washer, rack mount
* Hardware used to secure test equipment into DRC-2A.
To rack mount the TVM, follow these steps:
1. Install the extension bracket mounts (ITEM 2) to the unit (one on each side) using
#8 kep nuts (ITEM 4).
2. Install the assembled unit in a rack using ¾-in. Phillips head screws (ITEM 8) and
lock washers (ITEM 11), as shown in Figure 2-1.
3. Hold the extension brackets (ITEM 3) in place at the back of the rack, and then
attach the brackets to extension bracket mounts (ITEM 2) using hardware ITEMS
5, 6, and 7.
4. Install screws (ITEM 8) through the extension brackets (ITEM 3) into the back of
the rack rails. Secure using #10 kep nuts (ITEM 7).
5. Tighten all screws and nuts, securing the assembly.
6. Insert the TVM into either front opening of the DRC-2A. Slide the unit into the
DRC-2A until it seats fully against the back flanges of the DRC-2A, and the Bezel
of the TVM is fully seated around the front of the DRC-2A.
7. Secure the TVM to the DRC-2A rack case using ½-in. Phillips head screws (ITEM
9) and tooth lock washers (ITEM 10). The installation is complete.
