General Operation
TVM Series Installation and Operation Handbook 59
Copyright © 2008, Harris Corporation
Eye Pattern and Jitter Pane Menu Selections
Pressing and holding the EYE function button or the DISPLAY PANE button in the
active Eye Pattern pane or Jitter Waveform pane selects the pane menu. Use the
SETUP POSITION knobs or the NAVIGATION buttons to navigate the Pane menu.
The Eye Pattern Pane menu is described in Table 3-20 for SD-SDI monitoring, and
Table 3-21 for HD-SDI monitoring. The Jitter Waveform pane menu is described in
Table 3-22. The difference between the two eye menus is the Trigger Mode selections
of 10 EYE and 20 EYE.
Table 3-20. Eye SD-SDI Pane Menu Structure
Selection Selection Option
10 Hz
100 Hz
JITTER HPF
1000 Hz
OVERLAY TRIGGER MODE
10 EYE
EYE PATTERN SETUP Press ENT
Table 3-21. Eye HD-SDI Pane Menu Structure
Selection Selection Option
10 Hz
100 Hz
JITTER HPF
1000 Hz
OVERLAY TRIGGER MODE
20 EYE
EYE PATTERN SETUP Press ENT
Table 3-22. Jitter Waveform Pane Menu Structure
Selection Selection Option
10 Hz
100 Hz
1000 Hz
10 kHz
JITTER HPF
100 kHz
Waveform Sweep JITTER WAVEFORM
MODE
Frequency Sweep
EYE PATTERN SETUP Press ENT
