Global Setup Menu Functions
136 TVM Series Installation and Operation Handbook
Copyright © 2008, Harris Corporation
Setup Menu and Alarm Tables
The following tables make up the global setup menu. “(Default)” is shown next to each
of the default menu selections. The Setup menu items are listed in Table 4-1 with their
corresponding Table and Description pages:
Table 4-1. Setup Menu Tables
Setup Menu Item Table Page Description Page
Video Format Menu 137 166
Waveform Setup Menu 141 167
Eye Pattern Setup Menu 52 168
Vector Setup Menu 142 169
Gamut Setup Menu 142 170
Picture Setup Menu 142 171
Audio Setup Menu** - -
Audio Alarms Menu** - -
Video Alarms, Digital Menu 144 191*
Video Alarms, Analog Menu 149 196*
Time Code Alarms Menu 155 198*
TS (Transport Stream) Alarms Menu 156 200*
Monitor Out/Generator A-B 159 174
Monitor Out/Generator C-D 160 174
Display Setup Menu 159 175
Communications Menu 162 177
System Menu 164 180
About Menu 165 186
* The alarm descriptions are in Section 5, “Alarm Descriptions.”
** For information on Audio, see the A3-OPT 2, A3-OPT 3, A3-OPT 5,
A3-4004, and A3-OPT 3/5-TL Installation and Operation Handbook.
