Videotek TVM9100PKG - Scaled to Composite (SD and HD Only); Standard

General Operation
70 TVM Series Installation and Operation Handbook
Copyright © 2008, Harris Corporation
Table 3-24. Vector Analog Pane Menu Structure
Selection Selection Option
75% ANALOG STANDARD
100%
POSITION Use H POS and V POS knob. Press KNOB for center.
SETUP Press ENT
Table 3-25. Vector SD-SDI Pane Menu Structure
Selection Selection Option
75% SD STANDARD
100%
OFF SCALE SD TO
COMPOSITE
ON
POSITION Use H POS and V POS knob. Press KNOB for center.
SETUP Press ENT
Table 3-26. Vector HD-SDI Pane Menu Structure
Selection Selection Option
75%
100%
HD STANDARD
75% + 100%
OFF SCALE HD TO
COMPOSITE
ON
POSITION Use H POS and V POS knob. Press KNOB for center.
VECTOR SETUP Press ENT
Standard
NOTE: This selection also is reflected in the Gamut display for the selected pane.
Standard is used to set the marks on the vector display. The marks on the vector help to
visualize the minimum/maximum value of a video signal. The position of the excursion
marks are 75% or 100% for analog, SD, and HD. Also, the HD standard can be
selected as 75% and 100% simultaneously.
Scaled to Composite (SD and HD only)
Also, with an HD or SD signal, the Scaled to Composite menu can be used to scale the
SD or HD vector to reflect a composite format.
