TVM Series Installation and Operation Handbook 13
Copyright © 2008, Harris Corporation
Section 2 ♦ Installation
This section provides information about inspecting, installing, and configuring the
TVM.
Inspecting the Shipment
Before installing the TVM, inspect the box and the contents. Report any damage to the
shipper and telephone the Harris Corporation Customer Service Department for service
and support (see Section 1, “Service Support”).
NOTE: Refer to the enclosed packing sheet for the latest list of items that are supplied with the
unit.
The box contains the following:
• One TVM Series monitor/scope
• One TVM Series Installation and Operation Handbook on CD
• One 75Ω terminator
• One detachable power cord
• One breakout connector (for LTC/GPI)
• One DVI to VGA adapter
• One SpyderWeb II Installation CD
• One SpyderWeb II Installation Guide
• One additional breakout connector or 37-pin connector, if the audio option was
purchased
Save the box and packing material for any future shipping requirements.
