Specifications
224 TVM Series Installation and Operation Handbook
Copyright © 2008, Harris Corporation
TVM Options
Item Specification
TVM-VTM-AAP Software Feature Upgrade. Advanced Analysis Package that adds
data analyzer functions in quadrant or full-screen views to the
TVM-10. (Included in TVM-40.)
TVM-A3-OPT 2 Advanced Audio Analysis Option. Bargraphs and CineSound
®
. View
up to 8 audio channels. Includes 4 analog stereo inputs, 4 AES/EBU
shared input/output pairs and 16 channels of embedded audio.
Analog monitoring outputs of up to 8 channels simultaneously.
TVM-A3- 4004 Audio Expansion module. Adds 4 AES/EBU input pairs. Only
available with A3-OPT 2.
TVM-A3-OPT 3 Advanced Audio Analysis Option. Bargraphs and CineSound®. View
up to 8 audio channels. Includes 4 analog stereo inputs, 8 AES/EBU
inputs with 4 shared output and 16 channels of embedded audio.
Analog monitoring outputs of up to 8 channels simultaneously.
TVM-A3-OPT 3TL Advanced Audio Analysis Option with 5x oversampling for enhanced
True Peak detection. Bargraphs and CineSound®. View up to eight
audio channels. Includes four analog stereo inputs, eight AES/EBU
inputs with four-shared outputs and 16 channels of embedded audio.
Analog monitoring outputs of up to eight channels simultaneously.
Channel-mapping, loudness, meter labels, and peak value reporting
included. All AES inputs are sample rate converted to 48 kHz.
TVM-A3-OPT 5 Full Dolby decoding. Advanced Audio Analysis Option. Bargraphs
and CineSound®. View up to 8 audio channels. Includes 4 analog
stereo inputs, 8 AES/EBU inputs with 4 shared output and 16
channels of embedded audio. Analog monitoring outputs of up to 8
channels simultaneously.
TVM-A3-OPT 5TL Advanced Audio Analysis Option with 5x oversampling for enhanced
True Peak detection and Dolby. Bargraphs and CineSound®. View
up to eight audio channels. Includes four analog stereo inputs, eight
AES/EBU inputs with four-shared outputs and 16 channels of
embedded audio. Analog monitoring outputs of up to eight channels
simultaneously. Channel-mapping, loudness, meter labels, and peak
value reporting included. All AES inputs are sample rate converted to
48 kHz. It also adds full Dolby decoding to the analog output. The
Dolby Output is selectable from any 1 of the 8 pairs of the assigned
input type (AES or Embedded). Further, selection of an AES or
embedded pair for the AUX meters is available in an eight-channel
display.
TVM-A3-OPT 3TO5 Adds Dolby decoding to existing TVM-A3-OPT 3 A-D and
TVM-A3-OPT 3-TL
TVM-OPT V2A Adds Lip Sync to the TVM-A3-OPT 3 or TVM-A3-OPT 5
RCU-1000 Remote control panel for the TVM series, VTM series, instructions;
replicates all of the front panel controls; RS-422 connection, includes
50 ft (15 m) of cable with RJ-11 connectors; One RU in height
TVM-WRTY1 Full Extended Warranty Plan: Adds three years to the standard two-
year warranty, including a one-year extension on the LCD display
warranty
TVM-WRTY2 Adds three years to the standard two-year warranty
SSC-2 Single standard case
PTC-2 Portable case with folding stand
DRC-2A Double Rackmount Case
