Installation
TVM Series Installation and Operation Handbook 17
Copyright © 2008, Harris Corporation
Table 2-2. Description of Back Panel Connectors
Key Label Description
9 A/B MON OUT Female BNC connector for monitoring of the
selected A or B input
If both digital A + B inputs are selected, the
output is input A (this output is a source
monitor only and does not include the
waveform, vector, audio, or alarm on-screen
information)
NOTE 1: With TVM-VTM-ASI, Inputs A and B
cannot be selected simultaneously
NOTE 2: With TVM-VTM-3GB, A/B MON OUT
can be used as a test generator output (when
selected using TVM-VTM-3GB option)
10 C/D MON OUT (not available with TVM-VTM-
ACV-2)
Female BNC connector for monitoring of the
selected C or D input
If both C + D inputs are selected, the output is
input C (this output is a source monitor only
and does not include the waveform, vector,
audio, or alarm on-screen information)
NOTE 1: With TVM-VTM-ASI Inputs C and D
cannot be selected simultaneously
NOTE 2: With TVM-VTM-HD/SD, C/D MON
OUT can be used as a test generator output
(when selected using TVM-VTM-3GB option)
11 REF (A, B) External reference input accepting blackburst
and tri-level sync (termination required for loop
mode)
12 DVI-I OUT DVI-I output used to monitor a digital video
interface (an adapter is supplied with the TVM
to connect a standard XGA monitor to the DVI
output)
13 LTC/GPI 26-pin, high-density, female, D-sub connector
for LTC, GPI, and TALLY input*
14 REMOTE RJ11 socket to connect to the remote control
panel*
15 ROUTER RJ11 socket to control routing switchers.*
16 USB USB 1.1 port to support memory device for
recall and storage of presets, DISP freezes,
and SDI data freezes; it also supports flash
updates and keyboard functionality
17 ENET RJ45, female, 10/100BaseT connection.*
18 Input 115-230V ~ 150-60 Hz
180W max. 2A max.
Power connector
19 (Power Switch) Power switch that toggles power to the unit
*See Appendix B, “Pinouts,” for the connections.
