General Operation
TVM Series Installation and Operation Handbook 33
Copyright © 2008, Harris Corporation
Table 3-6. Description of Waveform Display Diagram
Field
Identifier
Field information Nomenclature
3 Filter
• Displayed as FLT, LP, CHR, BOW (Bowtie), R-Y
• This can be selected in the COMPOSITE or
COMPONENT FILTER submenu of the WFM Pane
menu
4 Standard Displays the Line Rate/Frame Rate [1080i/59.94]; this is
selected in the VIDEO FORMAT > VIDEO A though D
CONFIGURE menu
5 Reference Displays the reference as INT, EXT (toggled by pressing
the EXT button)
6 Gain Displays the selected gain; Gain ranges are 0.5 to 15.0
(change by pressing the STEP or VAR button)
7 Amplitude cursor readout Displays the amplitude cursor as AMP and the selected
numerical value followed by the unit or measure (mV, units,
or IRE)
8 Time cursor readout Displays the time cursor as TIME and the selected
numerical value followed by the unit or measure (µs)
9 Line select information Line select is shown as Line number with the ODD or
EVEN field (odd or even field will only show for interlaced
Video Formats)
10 WFM graticule Shows the WFM RGB, YCBCR, or Composite graticule; the
graticule is dependent upon the Video format, Zoom, and
scale selections
11 Scale Indicates the major graticule indications for time
12 Zoom
• Displays Zoom when enabled
• Blank when Zoom is disabled
• Press the ZOOM button to cycle through the ZOOM
modes
Graticules are configured by selecting the Video Input Format along with the
appropriate Waveform Setup scale adjustment (Units, %, or Volts). The scales can also
change when ZOOM is pressed.
Figure 3-7 to Figure 3-9 illustrates some waveform graticules with the critical
amplitude limits for the video formats that can be displayed by the TVM. The critical
amplitude limits are indicated on the screen by special dashed lines.
NOTE: When in VAR mode for all waveform scales, the graticule scale and numeric identifiers
will not be shown. Only the graticule lines will be displayed.
