Bit Controller/Motor error Remarks
6 Encoder error
The encoder (BK5120) sends a status update at least every second. A
timer in VVS is set to 4 seconds and is reset when this status has
been received. When the timer times out, this bit is set.
A
7-15 Spare -
Remarks
A Automatic cycle must be stopped and an operator message displayed.
B Automatic cycle must be continued until apply of material on drum and an operator
message displayed.
6.4.4 Actual position measurements (word 3-9)
Word Material position Dimension Remarks
3 Actual left edge 0.01 mm -
4 Actual right edge 0.01 mm -
5 Average width 0.01 mm -
6 - - Reserved for future use
7
Average length
1
0.1 mm Measured length BR and
TR
8 Angle Leading edge 0.01 degree Breaker only
9 Angle Trailing edge 0.01 degree Breaker only
Notes:
1. If split breaker material is handled, the words in the extended status (13, 14 and 15)
are used.
For 'normal' breaker material, word 7 in the actual position measurements is used.
The update rate of the measurements is 1000 ms. So every second a new value will be
sent to the PLC.
The Breaker average length is based on 300 length measurements. The Tread length
measurement is based on just one length measurements.
The breaker average width is based on the last 150 camera width measurements (in the
body). The average length and the average width are valid after a centering ready (when a
centering cycle is finished).
PARAMETERS
Status buffer
6
THINKING FORWARD
VMI Vision System VVS (OL82) VVSX 13.0.12.0, VVSU 3.0.6 / 4 / 2016-07-11 / pd#175592
6-20
