120 Creating PowerLine Methods
3. When the table entries are complete, keep the Analysis Plan and File Sheet as a
permanent record of your table.
Detector table entries affect the two UV/Vis detectors (Waters 486 and 490E). There is a
separate sensitivity parameter for the Waters 410 RI detector and Waters 431/432
Conductivity detector. Sensitivity is not under time control for these detectors.
Sample Detector Table
Figure 6-10 illustrates a detector table.
Figure 6-10 Detector Table Example
6.3.2 Programming the Detector Table
Figure 6-11 illustrates the steps involved in using the Detector Table screen to create a
detector table. Use this flowchart for quick reference once you become familiar with your
Waters 600E system.
410 Sens 1024 431/432 Sens 0.0005
Time Det/Chan Wavelength AUFS
Initial 1 254 0.1
3.10 1 240 0.005
4.62 1 245 0.01
To Next Page
