Creating a Detector Table 123
6.3.3 Entering Parameter Values in the Detector Table
To enter the parameter values into the Detector Table (see Figure 6-12):
1. Move the cursor to the Table # field.
2. Type a table number between 1 and 15. Press Enter.
If a detector table is already stored under this number, it now appears on the screen.
You can overwrite or edit this table, or enter another table number.
The detector table always runs with the gradient and event tables of the same
number within a method.
3. If you are using an RI detector:
a. Move the cursor to the 410 Sens field.
b. Type the required operating sensitivity. Valid values are 1, 2, 4, 8, 16, 32, 64, 128,
256, 512, and 1024.
c. Press Enter.
You cannot change this value during a run nor can you program it by time.
4. If you are using a conductivity detector:
a. Move the cursor to the 431/432 Sens field.
b. Type the required conductivity sensitivity in µS. Valid values are 0.1, 0.05, 0.02,
0.01, 0.005, 0.002, 0.001, 0.0005.
c. Press Enter.
5. If you are using a UV/Vis detector (Det #1 and/or Det #2):
a. Move the cursor to the Time field.
b. Type an appropriate value for the time (0.00 to 655.34 minutes) at which a
change is to occur. Press Enter. (You can use the same time value for Det #1 and
Det #2.)
Save Saves the table currently displayed and erases the
previous values. You must save the table before leaving
this screen.
Help Displays the Help screen associated with the Detector
Tables screen.
Table 6-4 Detector Table Screen Keys (Continued)
Key Function
