GENERAL INFORMATION
SAFETY
Protections (memory of
the last 100 faults /
alarms with date and
time)
DC link overvoltage.
DC link undervoltage.
Overtemperature at the inverter and at the motor.
Overcurrent at the output.
Motor overload (I x t).
Braking resistor overload.
CPU (watchdog)/EEPROM fault.
Incremental encoder fault.
Short-circuit at the output.
Phase-ground short-circuit at the output.
External fault.
Auto-diagnosis fault and programming error.
Serial communication fault.
Phase loss at the input.
HMI-MVW-01 interface connection fault.
APPLICABLE
STANDARDS
Electromagnetic
compatibility
EMC directive 89 / 336 / EEC – industrial environment.
EN 61800-3 (EMC - Emission and Immunity) standard.
CEI - IEC 61800
Adjustable Speed Electrical Power Drive System.
Part 4 - General Requirements.
Part 5 - Safety Requirements.
HUMAN MACHINE
INTERFACE
Command
Start/Stop, Parameterization (Programming of general functions).
Increase/decrease the speed.
JOG, Forward/Reverse selection, Local/Remote selection.
Supervision (Reading)
Speed reference (rpm).
Motor speed (rpm).
Value proportional to the speed (e.g.: m/min).
Motor frequency (Hz).
TDC link voltage (V).
Motor torque %.
Output power (kW).
Energized time (h).
Operation time (h).
Motor current (A).
Motor voltage (V).
Inverter status.
Digital input status.
Digital output (transistor) status.
Relay output status.
Analog input values.
100 last erros in the memory with date and time.
Fault/alarm messages.
AVAILABLE
RESOURCES /
FUNCTIONS
Options
Fieldbus network communication kits (internal inverter installation)
Profibus DP
DeviceNet
Ethernet Kit
Profinet Kit IO
Modbus kit TCP
I/O expansion kit
MVW01 | 2-4
