GENERAL INFORMATION
Table 2.6: Water Cooled Models - 3 level
Rated Current
(1)
Motor Rated Power
(2)
Dissipated Power
(3)
ND HD
ND HD
ND HD
[A]
Models
[HP] [KW] [HP] [KW]
[KW]
Frame
size
3300 V
265 234
MVW01 0265 T 3300
1700 1270 1500 1120 10.281 9.154
308 270
MVW01 0308 T 3300
1970 1470 1730 1290 11.91 10.467
359 315
MVW01 0359 T 3300
2300 1710 2020 1500 13.94 12.18
419 364
MVW01 0419 T 3300
2680 2000 2330 1740 16.463
14.144
460 423
MVW01 0460 T 3300
2950 2200 2710 2020 18.273 16.637
598 533
MVW01 0598 T 3300
3830 2850 3420 2540 24.259 21.602
AW
672 582
MVW01 0672 T 3300
4310 3210 3730 2780 26.695 23.019
789 684
MVW01 0789 T 3300
5060 3770 4380 3270 31.758
27.2
874 803
MVW01 0874 T 3300
5600 4170 5150 3830 35.638 32.386
1136 1013
MVW01 1136 T 3300
7280 5420 6490 4840 47.969 42.617
CW
1214
1052
MVW01 1214 T 3300
7780 5800 6740 5020 50.472 43.002
1311 1204
MVW01 1311 T 3300
8400 6260 7710 5750 55.166 49.997
1704 1520
MVW01 1704 T 3300
10920 8130 9740 7260 74.840 66.244
DW
1748 1606
MVW01 1748 T 3300
11200 8340 10290 7670 75.678 68.618
1853 1704
MVW01 1853 T 3300
11870 8850 10920 8130 83.066 76.157
2272
2025
MVW01 2272 T 3300
14560 10850 12980 9670 103.64 91.307
EW
2622 2408
MVW01 2622 T 3300
16800 12520 15430 11490 110.332 99.99
3409 3039
MVW01 3409 T 3300
21840 16270 19470 14510 149.680 132.488
2xDW
3496 3211
MVW01 3496 T 3300
22400 16690 20570 15330 151.356 137.236
4545
4051
MVW01 4545 T 3300
29120 21700 25960 19340 207.280 182.614
2xEW
4160 V
235
211
MVW01 0235 T 4160
1900 1410 1700 1270 12.315
11.15
281 254
MVW01 0281 T 4160
2270 1690 2050 1530 14.62 13.26
312 285
MVW01 0312 T 4160
2520 1880 2300 1720 16.23 14.82
338 306
MVW01 0338 T 4160
2730 2030 2470 1840 17.526 15.96
382 345
MVW01 0382 T 4160
3090 2300 2790 2080 19.732 17.873
392 360
MVW01 0392 T 4160
3170 2360 2910 2170 20.424 18.622
429 390
MVW01 0429 T 4160
3470 2580 3150 2350 21.8 19.99
527
475
MVW01 0527 T 4160
4260 3170 3840 2860 26.518 23.983
550 495
MVW01 0550 T 4160
4440 3310 4000 2980 27.661 24.950
AW
642 581
MVW01 0642 T 4160
5190 3860 4690 3500 33.995 30.093
729 658
MVW01 0729 T 4160
5890 4390 5310 3960 38.488 34.811
815
741
MVW01 0815 T 4160
6580 4900 5990 4460 42.582 39.015
963 871
MVW01 0963 T 4160
7780 5800 7040 5240 49.976 45.339
1045 945
MVW01 1045 T 4160
8440 6290 7630 5690 54.221 49.058
CW
1086 984
MVW01 1086 T 4160
8770 6540 7950 5920 58.511 53.025
1223
1112
MVW01 1223 T 4160
9880 7360 8980 6690 65.385 59.776
1413 1284
MVW01 1413 T 4160
11410 8500 10370 7730 75.344 68.533
1568
1424
MVW01 1568 T 4160
12670 9440 11500 8570 83.802 75.934
DW
1630 1482
MVW01 1630 T 4160
13170 9810 11970 8920 89.128 81.306
1927
1742
MVW01 1927 T 4160
15570 11600 14070 10480 105.540 95.205
2090 1899
MVW01 2090 T 4160
16880 12580 15340 11430 114.96 103.95
EW
2200 1988
MVW01 2200 T 4160
17770 13240 16060 11960 117.022 106.05
2445 2223
MVW01 2445 T 4160
19750 14710 17960 13380 130.770 119.552
3136 2851
MVW01 3136 T 4160
25330 18870 23030 17160 167.604 151.868
2xDW
3260 2964
MVW01 3260 T 4160
26330 19620 23940 17840 178.256 162.612
4180 3800
MVW01 4180 T 4160
33760 25150 30690 22870 211.08 190.41
2xEW
(1) Overload capacity:
HD: Heavy Duty: 150 % overload during 60 seconds every 10 minutes.
MX: Maximum Current: overload is not allowed.
(2) The motor rated power takes into account the operation with 0.87 power factor and 96 % efficiency at full load;
(3) Dissipated Power in the power arms and 12-pulse rectifier.
MVW01 | 2-10
