July 2019
2-6
Xerox® B210 Service Manual
06-100 / 200 , 07-110
Initial Release
Status Indicator RAPs
06-100 / 200 Laser Module (LSU) Motor RAP
BSD-ON:BSD 1
The machine has detected that the Laser Module Drive Motor is not working correctly.
WARNING
Do not perform repair activities with the power on or electrical power supplied to the
machine. The machine could activate and cause serious personal injury when the power
is on or electrical power is supplied.
DANGER: Ne pas effectuer de dépannage avec le contact principal activé ou avec l'ali-
mentation électrique appliquée à la machine: celle-ci pourrait démarrer et causer de
g
raves blessures.
AVVERTENZA: Non effettuare alcuna riparazione con la macchina accesa o con l'ali-
mentazione elettrica inserita. La macchina potrebbe avviarsi all'improvviso e causare
gr
avi ferite.
VORSICHT: Es dürfen keine Reparaturarbeiten durchgeführt werden, solange das Gerät
ei
ngeschalten oder mit der Stromquelle verbunden ist. Das Gerät kann u.U in den Aktiv-
Zustand übergehen und somit erhebliche körperliche Schäden verursachen.
AVISO: No realice reparaciones con la máquina encendida o conectada a la corriente. La
máq
uina podría activarse y ocasionar daños personales graves.
WARNING
Use eye protection when performing the following procedure. Failure to wear eye pro-
tection could result in serious personal injury.
DANGER: Porter des lunettes de sécurité pendant la procédure suivante. À défaut, de
g
raves blessures peuvent se produire.
AVVERTENZA: Indossare occhiali di protezione durante la seguente procedura. In caso
co
ntrario, si possono provocare gravi ferite.
VORSICHT: Folgende Verfahren dürfen nicht ohne Schutzbrille angewandt werden. Die
Ni
chteinhaltung dieser Regel kann zu ernsthaften körperlichen Verletzungen führen.
AVISO: Use gafas de protección para realizar el procedimiento siguiente. No proteger
l
os ojos puede ocasionar daños personales graves.
Procedure
Check the Main Wire Harness and connectors on the Laser Module. The connections are
secure.
YN
• Verify there are no broken or defective wires
and that no contamination is present
• Disconnect and securely reconnect the harness.
Check the harness for a short circuit or open circuit. The harness is OK.
YN
• Verify there are no broken or defective wires
and that no contamination is present
• Install a new Flat Cable, PL 4.
1 Item 1.
Install a new LSU, PL 4.1 Item 22.
Go to SCP 04 Final Actions.
07-110 Paper Tray 1 Empty RAP
The Tray Empty Sensor failed to detect paper in the tray
BSD-Reference: BS
D 1
Initial Actions
Ensure that paper is loaded in the tray. Clear any jammed sheets. Refer to Section 7: Trouble-
shooting in the Xerox® B210 User Guide for detailed instructions on clearing paper jams.
Procedure
Check the Sensor Actuator, PL 4.5 Item 5. The actuator moves freely and is undamaged.
YN
Clear any debris obstruct
ing the actuator path.
Check for 3.3 VDC at the Exit Sensor Voltage is present at the Exit Sensor.
YN
Check for 3.3 VDC at the Main PWB. Voltage is present at the Main PWB.
YN
Verify all voltages are present between the HVPS PWB and the Main PWB. The
v
oltages between the HVPS PWB and the Main PWB are present.
YN
• Install a new HVPS PWB, PL
4.1 Item 2.
• Install a new Main PWB, PL 1.1 Item 7.
Install a new Exit Sensor, PL 4.5 Item 3.
Install a new Exit Sensor, PL 4.
5 Item 3.
Install a new Exit Sensor, PL 4.
5 Item 3.
If the problem is intermittent, check the circuit of the Exit Sensor.
To Next Page
