July 2019
2-10
Xerox® B210 Service Manual
08-600 , 09-100
Initial Release
Status Indicator RAPs
08-600 Paper Jam in Duplex Area RAP
The machine has detected a paper jam in the Duplex Area.
BSD-Reference: 10.
2 Print Exit
Initial Actions
Remove jammed sheets from duplex area. Refer to Section 7: Troubleshooting, in the Xerox®
B210 User Guide for detailed instructions on clearing paper jams.
Ensure that the paper guide and machine settings are correct for the paper that is loaded in the
tr
ay.
Procedure
Check the Sensor Actuator, PL 4.5 Item 5. The actuator moves freely.
YN
Remove all debris that may be causing trouble at the Sensor Actuator.
Check for obstruction to unblock and clear the Exit Sensor. The sensor is OK.
YN
• Verify the sensor connect
or is firmly seated
• Verify there is no contamination present.
• Check for an open or short circuit.
• Install a new Exit Sensor, PL 4.
5 Item 3.
Check the following parts for wear or damage:
• Duplex Paper Guide, P
L 4.2 Item 6.
• Duplex Upper Guide, PL 4.2 Item 5.
• Spring, PL 4.2 Item 4.
• Roller Bushing, PL 4.2 Item 9.
• Duplex Gate, PL 2.1 Item 7.
NOTE: Verify the Duplex Gate is seated correctly and moves freely without binding.
• Exit Paper Guide, PL 2.
1 Item 6.
• Install new components as required:
– Duplex Assembly, PL 4.
2 Item 11.
– Rear Cover Assembly, PL 2.1 Item 3.
09-100 Toner Cartridge Near End of Life RAP
The Toner Cartridge life is less than 10%.
Procedure
1. Check the remaining life of the Toner Cartridge by using one of the methods listed below:
• Print a Supplies Information Report, GP 2
.
• Open Easy Printer Manager, check Toner Life.
• Open the CWIS application. Select; [St
atus, Supplies, Print Cartridge].
NOTE: The workstation and printer machine must be networked to use the CWIS
applicat
ion.
2. Check the remaining life of the Toner Cartridge.
3. If the Toner Cartridge has reached end of life, Switch off the machine and Install a ne
w
T
oner Cartridge.
